Your knees can be irritated by the repeated motion of cycling, especially if you try and do too much too quickly, or your bike set-up isn’t quite right. Here are the most common causes and solutions to the overuse knee pain that cyclists sometimes suffer.
We’ll look first at the different types of knee injuries for cyclists and where exactly they occur, then examine the main causes of knee injuries. These can include changes to your riding patterns, changes to your bike set-up, and biomechanical quirks that everyone has to some degree. We’ll follow up with some recommended solutions for each cause.
Overuse vs traumatic knee injuries
A study published in the American Journal of Sports Medicine of more than 1,500 cyclists undertaking the six-day Cycle Across Maryland ride in the US found that 24% of all riders reported knee pain, with inexperience and lack of pre-ride conditioning accounting for many of the overuse injuries described – those not caused by direct trauma or accident. It’s important to draw this distinction, as traumatic injuries result from a very different mechanism and are treated quite differently too.
Overuse injuries arise from repetition. The accumulation of excessive loads over time exceed the body’s ability to dissipate energy, leading to damage on a microscopic level which, if not given chance to recover, sets up a chronic cycle of improperly healed inﬂammation and tissue degeneration, experienced as pain, weakness and stiffness.
Where exactly do knee problems occur?
The structures of the knee BikeRadar
This requires a basic explanation of the anatomy and biomechanics of the knee. In simple terms the knee is a hinge joint between the femur (thigh bone) and the tibia (shin bone), acted upon by the large muscles of the thigh.
At the back, the hamstrings ﬂex the knee, as well as helping the gluteal muscles to extend the hip joint. At the front, the quadriceps extend or straighten the knee by attaching to the tibia via your patella (the kneecap). This has its own articulation with the thigh bone – the patellofemoral joint, or ‘PFJ’ – which often plays a lead role where knee pain is concerned, since bending the knee compresses the joint.
Those ‘large muscles of the thigh’ can get very large with regular two-wheeled activity, and this is where problems start.
The normal movements of the knee are ﬁnely balanced, and with different muscle groups pulling at the patella from slightly different angles, it doesn’t take much to upset things. Add to this tight muscles restricting normal motion, varying saddle heights and feet ﬁrmly planted in angled cleats, and it’s amazing we don’t all cycle with ﬁxed grimaces.
Every pedal stroke ﬂexes and extends the knee joint, yet never fully extends it. The powerful push (extending) phase starts with the knee ﬂexed to around 110º, reaching about 35º before ﬂexing back through the pull phase. It can all add up to years of relative imbalance between those powerful muscle groups and unnatural forces about the knee.
For a more in-depth explanation of what is happening where, read our guide to Cycling knee pain: the problem areas.
So what are the main causes of knee injuries?
Knee conditions can be generally divided into three broad categories: cycling-speciﬁc, bike-speciﬁc and cyclist-speciﬁc.
Speciﬁc overuse injuries usually arise from a combination of factors across all three of these domains – the secret is to identify which is contributing the greatest offence and make a focused change for the better.
1. Cycling-speciﬁc causes
Changes in training patterns are one of the most common causes of knee pain for cyclists T.T.
These can be defined as changes in training that exceed the body’s capacity for normal function and repair, including:
- Greatly increasing distance & duration of rides
- Sudden increase in training intensity
- Riding more hills than usual
- Using high gears & low cadence
Unfortunately, our cycling enthusiasm is to blame for one of the most common causes of knee pain. You know the story – new season, new goals, a change in the weather or a new bike maybe. With renewed vigour we resolve to cast off the winter’s sloth and get down to some serious riding, with scant regard for how our knees might bear up to the onslaught.
‘No pain, no gain’ only holds true within certain limits. Drastically increasing anything to do with our riding habits – distance, speed, intensity, tough terrain or tough gears – without gradual acclimatisation is just asking for trouble. That envelope of function is exceeded, and damage accumulates until the forces through the knee joint are reduced.
Even changing from long, steady winter base training to shorter, sharper rides in the early season can cause problems; if the body’s not used to a speciﬁc type of training, it’s interpreted as a drastic change.
Getting your saddle height right is crucial for avoiding knee pain BikeRadar
These are changes in equipment or a position on the bike that the body’s not used to, including:
- Saddle height and saddle setback
- Length of cranks
- Cleat position or excessive wear
The same basic principle applies here: if radical changes are made to equipment and position, problems are very likely to arise.
The key measurements affecting the knee are saddle height and setback, with crank length affecting not only the absolute saddle-to-pedal distance, but also the force required to generate one full pedal revolution. Longer cranks (essentially the equivalent to using stiffer gears) increase the forces transmitted across the patellofemoral joint (explained below), thus amplifying the likelihood of cumulative damage.
The patellofemoral joint – or PFJ – comprises:
- Femur– the thigh bone, the biggest bone in the body, with the hip joint at one end and the knee at the other
- Patella – the kneecap, a ‘ﬂoating’ bone which sits in the tendon coming from the quadraceps
- Tibia – the shin bone, where the muscles of the thigh attach in order to lever the knee joint
If you’re new to cycling, or to a particular bike, a lack of frame of reference can mean it’s sometimes difﬁcult to establish exactly where the problem might lie. There’s no universally agreed, correct way to set your bike up, but most reputable bike shops will provide advice, with some offering an adjustable bike-ﬁt jig and several decades of experience.
3. Cyclist-speciﬁc causes
Anatomical differences may contribute to problems in one particular leg Tom Dunkley / Getty
These are biomechanical abnormalities that compound cycling- and bike-speciﬁc causes, including:
- Anatomical discrepancies (e.g leg length)
- Legacy of old injuries
- Inﬂexibility & muscle tightness
- Muscle weakness (including core muscles)
They are intrinsic causes (originating within the body), rather than extrinsic (originating outside the body). As such they often manifest quite stealthily, contributing to the two categories above, such that our training load reaches a particular threshold, at which point we are suddenly troubled with knee pain.
Anatomical differences, such as leg length discrepancies, may contribute to problems in one particular leg, but in reality we all favour one leg over the other (it’s the one with the thigh closest to the seatpost when pedalling), in part explaining why knee pain seldom affects both legs equally.
Each individual’s body has also had to respond to a lifetime’s knocks, scrapes and more serious injuries, which it does by moving in subtly different ways, initially to protect the injury, and then, once healed, because it’s got used to these new movements as being normal.
Damage to your knee could be caused by you, your bike or the way you cycle
But the cumulative effect of all of these can upset the ﬁne balance of forces the knee has to deal with. This dissipation or ‘coping’ with energy transmitted through the joint is done largely by the muscles and their tendons, so it stands to reason that tight, inelastic muscles can indirectly contribute to increased forces through the PFJ.
What are the solutions to knee pain?
Once you’ve identified changes in the way you ride, you can focus on healing the injury Jon Sparks / Immediate Media
Now you’re aware of these three general problem areas, the ﬁrst question to ask is: what’s changed? The answer may not be immediately obvious, but without a change it’s unusual to run into problems.
- Have you changed your position, or components on the bike?
- Have you started training differently, or further or harder?
- Have you reached a threshold you just don’t seem to be able to progress beyond without knee pain?
Once you’ve identiﬁed the most likely culprit, it’s then a case of making changes to bring your knee-related activities back within the envelope of function so healing can occur.
1. Cycling-speciﬁc solutions
These involve unloading the problem area, most often the PFJ (see explanation above). This means easing back on your training until you’ve redressed the balance. Carrying on blithely, hoping it will go away is only likely to set you up for longer term problems.
This isn’t to say you have to stop riding entirely. Only you can know what you’re capable of, but a rule of thumb is to exercise painlessly as much as possible. Lower distances, fewer hills and lower gears can all help you maintain ﬁtness without destroying your knees, while you make concurrent changes across the other two domains.
Of course, prevention is far better than cure, so make only gradual increases to your training (no more than 10-15% more each week) and watch out for the transition between low and high intensity where hours may remain static (or even decrease), masking a sudden change to training. Keeping a diary of your rides is essential to get to the bottom of this type of problem.
2. Bike-speciﬁc solutions
Again these revolve around making small changes when they are required in order to prevent problems from occurring in the ﬁrst place.
Always note down the measurement of anything before changing a component: saddle height, setback and cleat position (the easiest way is to draw round the old ones with a felt tip pen before removing them).
Cleats with ‘ﬂoat’ (small amounts of rotation when engaged) are a good idea, and consider swapping those super-long cranks for a pair of 170mm ones.
3. Cyclist-speciﬁc solutions
Cyclist-specific solutions are possibly the trickiest to tackle Tim De Waele
These are possibly the trickiest to tackle. Having said this, general measures such as hot baths to loosen tight muscles, followed by regular stretching of large muscle groups (quads, hamstrings, adductors and gluteal muscles) can increase ﬂexibility to cope better with pressures across the PFJ.
Read our separate article on fixing knee pain for advice on how to target different areas of the knee. It’s worth emphasising that the practice of pre-ride stretching has not been shown to reduce the likelihood of picking up an overuse injury. This further reinforces the message that vigorous stretching of cold muscles is at best ineffectual and at worst potentially damaging.
The role of core muscles should also not be overlooked – the abdominal, back and especially pelvic muscles all contribute to taking the strain off the major leg muscles. Read our guide to 10 core exercises for cyclists for more information.
What else can be done about knee pain?
You may wish to enlist the help of a physiotherapist Caiaimage/Trevor Adeline
It sounds awful, but the good news is the vast majority of these injuries improve with simple non-operative interventions, the key being to rehabilitate within the boundaries of the body’s natural capacity for repair, or what’s been termed the ‘envelope of function’ in the Sports Medicine & Arthroscopy Review.
Whatever the nature of your knee pain, it’s crucial to listen to your body and react accordingly. Occasional pain while on the bike means you’re just outside the limits of your body’s capacity for repair. Consequently, any adjustments needed are likely to be minimal, with little upset to your training. On the other hand, pain that’s present every time you cycle and persists when you’re off the bike implies your body’s crying out for respite.
You may wish to enlist the help of a physiotherapist – those within the specialities of sports and manipulative physiotherapy might be best equipped to help gradually straighten out a lifetime’s abuse. Check out www.csp.org.uk for a list of registered practitioners, but keep your ear to the ground and ask around your local club for recommendations too.
If you wish to seek medical advice for your knee problem, it’s worth remembering that family doctors are generalists but many have a specialist interest. Ask at your local practice whether one of the GPs has an interest in musculo-skeletal and/or sports medicine – they may even run a specialist clinic at your practice.
If nothing is available in the community, it’s not unreasonable to ask for referral to a specialist at a nearby hospital. One who majors on sports injuries would be the ideal, but in NHS speak (www.nhs.uk) the closest you may get when searching is a ‘soft tissue knee service’.
